Even athletes sit on the tandem to get together to have more pace and more fun.
EVOLUTION TANDEMS
Tandem
The Evolution tandems with their innovative frame design represent the new standard ...
Continue reading
So far, the dimension of the bottom tube (oval tube between the two bottom brackets) was limited by the width of the bottom brackets, 73 mm. The new bottom bracket standard BB386 (86 mm case width) now makes larger dimensions possible. The now more stable bottom tube makes it possible to eliminate the lateral tube * while still having the same ride quality and lateral stiffness. This leads to a significant reduction in the frame weight. While Santana were making such radical changes to thair frame design they also adopted industry standard 1 1/2″ – 1 1/8″ tapered forks and 31.6 mm seatposts so owners can run any stem or seatpost they like
Of course, all Evolution tandems are also available with Santana's Z-Couplers for easy travel with the Safecase case.
The new standard equipment is equipped with the Ultegra Di2 2x11 drivetrain with a gear ratio that is comparable to the previous 3x10 drivetrain. Chainrings 34/50 alternatively 36/52 and 11-speed cassettes with 11-40 teeth, alternatively 11-42T (11-46T / 11-34 ...) and the rear 10 "disc brake Gen4 free of extra charge.
Pro components: carbon fork with 10" disc brake, carbon cranks with timing belts, new Spinergy wheels, carbon handlebars and seat posts, and much more ...
For further equipment options see configurator.
* Introduced by Santana in 1983. So far standard for high-quality tandems.ExoGrid® technology
| Modell | material | weight** | from EURO* |
|
eSCape Scandium Di2 |
Scandium aluminium 7005 |
13,8 kg |
9340,- € |
|
eSCape Scandium |
Scandium aluminium 7005 |
|
plus |
|
Titan Journey |
|
13640,- € |
|
|
Titan Journey |
|
plus |
|
|
Synergy Ti-Carb Di2 |
ExoGrid® titanium/carbon |
|
17440,- € |
|
Synergy Ti-Carb |
ExoGrid® titanium/carbon |
|
plus |
|
Evolve Carbon Di2 |
carbon |
|
21000,- € |
|
Evolve Carbon |
carbon |
|
plus |
Reveal Pro
- Fork: Carbon tapered 1,5 > 1 1/8" with 10" Disc
- Headset: Cane Creek 110 1,5 >1 1/8"
- Hubs: Spinergy PBO Wheelset
- Rims: Spinergy PBO Wheelset
- Spokes: Spinergy WHT(rund) BLK (aero) Armid
- Tires: Continental 4Season 28 (32/25)-622
- Crankset: Santana BB386 Carbon 175/170 modular spider 50/43, 52/36 Gates Timing Belt CCX
- Bottom brackets: Santana BB386 new
- Shifting system: Shimano Ultegra Di2 electric 11-speed
- Front Deraileur: Shimano Ultegra Di2 electric 2-speed
- Brakeshifter: Shimano Ultegra Di2
- Cassette: Shimano Ultegra 11-speed 11-40
- Chain: Shimano / KMC / Gates Timing
- Brakes: front mechanical 10" Disc Caliper / rear mechanical 10" Disc Caliper
- Saddle: Terry Fly / Butterfly Titan
- Seatpost Captain: Carbon 31,6 mm
- Seatpost Stoker: Carbon 31,6 mm opt Suspension
- Handlebar Captain: Road Carbon Ergo 31,8 mm 44 cm
- Handlebar Stoker: Carbon Ergo Stoker 47 cm
- Stem Captain: Controltech (Ritchey) 28,6 x 31,8 mm
- Stem Stoker: Controltech verstellbar AL 31,6 x 31,8 mm blk
Options
- Customisation: Custom geometry
- Z-Couplers: allow the tandem to be stowed within a suitcase-sized package
- Headset: Chris King
- Rims: Spinergy FCC 3.2 Carbon
- Tires: Continental Gatorskin HS 32-622
- Shifting system: Shimano Dura Ace 11-speed Di2
- Front Deraileur: Shimano Dura Ace 2-speed Di2
- Brakeshifter: Shimano Dura Ace Di2
- Cassette: Shimano Ultegra 11-34 XT 11-42/46 / XTR 11-speed 11-40
- Brakes: front hydraulic 10" Disc Caliper / rear hydraulic 10" Disc Caliper
- Saddle: Ritchey WCS
- Seatpost Stoker: CaneCreek ShortTravel Suspension / Ritchey Carbon
- Handlebars on request also MTB or upright ouringbars
- Stem Stoker: with long Stokerboom + riser
- Pedales: Shimano SPD ...
- Child Stoker crankset kit and crankarm shorteners
- Rack:Tubus Cosmo / Stainless steel
- Lowrider-special / Fender / light / (magnetic)bottle cage
- E-drive: Ansmann 4.2 front-wheel drive / add-e Next roller drive rear wheel
Reveal Standard
- Fork: Pro-Carbon Tapered 1,5 > 1 1/8"
- Headset: Cane Creek Hellbender 70 1,5 >1 1/8"
- Hubs: Hadley Tandem spoke Made in USA
- Rims: Velocity Fusion
- Spokes: Spokes: DT Comp 2 x 1,8 x 2
- Tires: Continental Gatorskin 32(28)-622
- Crankset: Santana BB386 AL 175/170 modular spider 50/43, 52/36 Gates Timing Belt CCX
- Bottombrackets: Santana BB386 new
- Shifting system: Shimano Ultegra Di2 electric 11-speed
- Front Deraileur: Shimano Ultegra Di2 electric 2-speed
- Brakeshifter: Shimano Ultegra 11/2-speed
- Cassette: Shimano XT 11-speed 11-40
- Chain: Shimano / KMC Timing
- Brakes: front Ultegra Caliper / rear 10" Disc Gen4
- Saddle: Terry Fly / Butterfly Crmo
- Seatpost Captain: Alloy 31,6 mm
- Seatpost Stoker: Alloy 31,6 mm opt Suspension
- Handlebar Captain: Road Alloy 44 cm
- Handlebar Stoker: Alloy Round 47 cm
- Stem Captain: Control 28,6 x 31,8 mm
- Stem Stoker: Controltech adjustable AL 31,6 x 31,8 mm blk
Options
- Customisation: Custom Geometry
- couplers allow the tandem to be stowed within a suitcase-sized package
- Fork: V-Brake CrMo (carbon)
- Headset: Chris King 1,5 >1 1/8"
- Hubs: Santana Classic
- Rims: Exal SP19 / DT-Swiss HX491/RR511 /
- Tires: Continental 4Season 32(28/25)-622
- Shifting system: Shimano Ultegra mechanical 11-speed
- Front Deraileur: Shimano Ultegra mechanical 2-speed
- Brakeshifter: Shimano Ultegra mechanical
- Cassette: Shimano Ultegra 11-34 / XT 11-42/46
- Brakes: front road Caliper Shimano Dura Ace
- Saddle: Terry TI / Ritchey Carbon
- Seatpost Captain: Santana/Ritchey Carbon
- Seatpost Stoker: CaneCreek short-travel / eeSilk Santana/Ritchey Carbon
- Handlebars: AL-Carbon 31,8 mm 45 cm/ on request also MTB or upright ouringbars
- Stem Stoker: with long Stokerboom + riser
- Pedales: Shimano SPD ...
- Child Stoker crankset kit and crankarm shorteners
- Rack:Tubus GrandTour/Logo/Cosmo/Fly
- Lowrider-special / Fender/ light / (magnetic)bottle cage
- E-drive: Ansmann 4.2 front-wheel drive / add-e Next roller drive rear wheel
SPORT TANDEMS
Tandem
In a quest to develop the easiest tandem to own and use we created the Smooth. Clean, maintenance free belt drives and internal gearing mean it’s always ready to go for a trip into town or down the boardwalk. The perfect accessory for an RV or beach house, the whole family will want to get in on the fun. Two frame sizes each incorporate a telescoping stoker seatpost to accommodate a wide range of rider heights. Quality components and a butted 7000 series aluminum frame for lightweight durability. 26 x 1.5” tires are fast rolling but stable, puncture resistant, and comfortable.
| material | weight** | EURO* | |
| Smooth |
Aluminium | from 17,1 kg | from 3590,- € |
Components
- Fork: CrMo 1 ¼" Ahead
- Headset: Tange
- Front hub: Classic Santana 36 h
- Rear hub: NuVinci N360 Stufenlose Nabenschaltung
- Rims: Velocity 36L
- Tires: Kenda Kwick Roller 26 x 1,5
- Crankset: Alum 175/170 Oktalink with carbon belt drive
- Shifting system: NuVinci N360
- Brakelever: MTB
- Brakes: Avid V-Brake / Rear 8 inch Disc
- Saddle: Velo Push Comfort
- Seatpost Captain: Aluminium
- Seatpost Stoker: Aluminium Telescopic
- Handlebar Captain: MTB Al 31,8
- Handlebar Stoker: MTB Al 31,8
- Stem Captain: Woodman/Controltech 31,8 x 31,8
5/15 Degree 70-150 mm - Stem Stoker: Controltech adj. Al Blk
Options
- Saddle: custom
- Seatpost stoker: Cane Creek shorttravel
- Stem stoker: long stokerboom + stem riser
- Pedals: Shimano Spd...
- Child stoker crankset kit
- Rack: Tubus Cosmo / Titan / lowrider-special
- fender
- light
- bottle cage
- E-drive: Ansman 4.2, 6.0, 8.0 frontdrive / add-e Next
CLASSIC TANDEMS
Tandem
The Nuovo Sport is our most affordable aluminum road tandem. With double-butted 7005-series aluminum tubing and Santana's high-quality tandem specific componentry, the Nuovo Sportis your opportunity to hit the road in style and comfort.
Stowaway Option: not available
| material | weight** | EURO* | |
| Nuovo Sport |
aluminium | 16,3 kg | 3.940,- € |
Components
- Fork: Santana CrMo 1 ¼"
- Headset: Tange 1 ¼"
- Hubs: Classic Santana 40 holes
- Rims: Exal Sp19 40L
- Spokes: 40 spokes Dt comp 2 x 1,8 x 2
- Tires: Continental Gatorskin 28-622
- Crankset: Alum-175/170 30/39/53
- Bottombrackets: Shimano Td Octalink129
- Rear deraileur: Shimano Deore
- Front deraileur: Shimano Road Triple
- Brakeshifter: Shimano 105 10/3F
- Cassette: Shimano Hg62 10-Speed 11-34
- Chain: Shimano/Kmc
- Brakes: Avid V-Brake
- Saddle: Terry Fly / Butterfly CrMo
- Seatpost Captain: Aluminium
- Seatpost Stoker: Aluminium, linear suspension
- Handlebar Captain: Road Al 31,8 44
- Handlebar Stoker: Aluminium stoker 47
- Stem Captain: Woodman / Controltech 31,8 x 31,8
5/15 degree 70-150 mm - Stem Stoker: Controltech adjustable Al Blk
Options
- Fork: Santana Carbon 1 ¼"
- Hubs: Hadley 40L / Shimano
- Rims: Velocity City Fusion
- Tires: Continental Gatorskin Hs 32-622
- Crankset: Alum-Carbon175/170
- Timing Drive: with Denterline Carbondrive Belt
- Rear deraileur: Shimano Xt
- Front deraileur: Shimano Ultegra
- Brakeshifter: Shimano Ultegra
- Cassette: Shimano Hg 81/ Xt
- Brake rear: 10 inch rear disk brake Gen4
- Saddle: Ritchey Contrail-Lady
- Seatpost: Stoker Cane Creek Shorttravel
- Handlebar Captain: MTB / Touring
- Stem: with long stokerboom + stem riser
- Pedals: Shimano Spd...
- child stoker crankset kits or crankarm shortener
- Rack: Tubus Cosmo / Titan
- Lowrider-Special
- Fender
- Light
- E-drive: Ansmann 4.2, 6.0, 8.0 / add-e Next
